Deck Permits in Manheim Township, PA: Everything You Need to Know

TL;DR—Deck Permits in Manheim Township, PA

  • You’ll almost always need a permit – A building permit is required if your deck is over 30” high; otherwise, you’ll still need a zoning permit.
  • The permit process involves paperwork and plans – You’ll need to submit detailed drawings, site plans, and a fee worksheet to the Township.
  • Strict building codes apply – Manheim Township has specific rules for lumber, fasteners, footings, railings, stairs, and more to ensure safety.
  • Don’t skip the permit – Building without one can lead to fines, forced removal, or safety issues. Hiring a local contractor like Keystone Custom Decks makes the process easier and stress-free.

Deck Permits in Manheim Township, PA

Dreaming of a beautiful new deck where you can relax, entertain, and enjoy the Manheim Township sunshine?

That sounds amazing.

But before you start sketching out your perfect design or picking out lumber, there's a crucial first step that people often overlook: understanding the local permit requirements.

Permits can conjure images of endless paperwork and bureaucratic headaches. But here at Keystone Custom Decks, we want to assure you that navigating Manheim Township's permit process doesn't have to be a nightmare.

We’ve put everything together in one easy-to-read place so you can go through this process with confidence.

In the end, you’ll have a deck that is not only beautiful but also safe, structurally sound, and compliant with all local ordinances.

Following is everything you need to know about getting a permit to build a deck in Manheim, located in the heart of Lancaster County.

Let’s get started!

Do You Need a Permit to Build a Deck in Manheim Township?

The short answer is: very likely, yes! Manheim Township, like most municipalities, has specific requirements for deck construction to ensure safety and maintain community standards.

Here's the key distinction:

Minigraphic 1
  • You need a building permit if: Any portion of your deck's walking surface is greater than 30 inches above the ground level, you need a building permit. This is the more comprehensive permit, ensuring structural integrity and compliance with the Uniform Construction Code (UCC).
  • Zoning Permit Required: Even if your deck's walking surface is 30 inches or less above the adjacent grade, you'll still need a zoning permit. This permit primarily deals with the placement of your deck on your property relative to property lines and other structures.

So, while a small, low-standing patio might not require a building permit, almost all decks will require some form of approval from Manheim Township. It's always best to check, so err on the side of caution!

Navigating the Deck Permit Application Process

Alright, so a permit is likely needed. Here's a step-by-step overview of what to expect when applying for your deck permit in Manheim Township:

  1. Gather Your Documents: This is where careful planning gets important. You'll need to submit a few key items:
    • Completed and Signed Building Permit Application: This is your official request to the Township. Make sure all applicable areas are filled out accurately.

Download Manheim Township's Permit Application

    • Completed Fee Schedule Worksheet (Residential): Deck permit fees in Manheim Township are typically based on the square footage of your proposed deck. You'll use this worksheet to calculate the fee, and an invoice will be provided when the permit is issued.

Download the residential fee worksheet

    • Two (2) Copies of Complete Plans and Specifications: This is where the detailed drawings of your deck come in. For simple decks, a "Typical Deck Framing Plan" might suffice, but it needs to clearly show:
      • Ledger size and connections (how it attaches to your house).
      • Beam span and size.
      • Joist size, span, and on-center spacing.
      • Cross-section of the deck construction.
      • Stairway, guardrail, and handrail details (if applicable).
    • Two (2) Copies of a Site Plan and Other Applicable Zoning Documentation: This is a drawing of your property showing the exact location and size of your proposed deck, along with dimensions to property lines. You can often request a copy of your property's site plan from the Planning and Zoning Department.



2. Submit Your Application: You can typically submit your application in person or via first-class mail. Manheim Township also has a Permit Portal for certain permit types; however, for a full deck building permit, direct submission with hard copies of plans is often preferred. It's a good idea to contact their Code Compliance Department to confirm the most current and efficient submission method.

3. Review and Approval: The Township's Building Codes Officer will review your submission to ensure everything is in order and complies with local codes. They aim to confirm required items within 5 days of receipt. This is where having clear, complete plans really pays off!

4. Fee Payment: Once your application is reviewed and approved, you'll receive an invoice for the permit fees.

You can typically submit your application in person or via first-class mail. While Manheim Township offers a Permit Portal for some permits, full deck permits typically require hard copy submission.

Specific Zoning, Design, and Code Requirements for Decks in Manheim Township

Here's where the nitty-gritty details come in, ensuring your deck is built to Manheim Township's high standards for safety and durability:

  • Lumber and Treatment: All lumber used for your deck construction must be Southern Pine, grade #2 or better, and pressure-treated per AWPA U1 (American Wood Protection Association). This ensures resistance to rot, decay, and insect infestation.
  • Framing Hardware and Fasteners: This is crucial for maintaining the structural integrity of your deck.
    • Corrosion Resistance: All hardware (joist hangers, cast-in-place anchors, post bases, connectors) and fasteners (screws, bolts, washers, nuts, nails) must be corrosion-resistant. This means they need to be:
      • Hot-dipped galvanized meeting ASTM A 153, Class D for fasteners 3/8" in diameter and smaller, or Class C for fasteners over 3/8".
      • Mechanically deposited zinc-coated steel with coating weights in accordance with ASTM B 695, Class 55, minimum.
      • Alternatively, stainless steel is also permitted.
    • Nails: Any nails used must be threaded to prevent them from popping out as the wood naturally expands and contracts with moisture changes.
    • Ledger Board Connections: If your deck is attached to your house via a ledger board, it should be a 2x8-inch board with proper flashing installed to prevent water intrusion into your home's structure. The connections for cantilevered framing methods must resist uplift.
    • Lateral Load Connectors: Your deck must have a minimum of two (2) lateral load connectors located within 24 inches of each end of the deck, each with an allowable capacity of not less than 1500 pounds. Additionally, a minimum of four (4) lateral load connectors, each with an allowable capacity of not less than 750 pounds, are required. These are crucial for preventing the deck from pulling away from the house in high winds or other lateral forces.
  • Footings:
Deck footings must be installed below the frost line to prevent shifting due to freeze-thaw cycles. In Pennsylvania, this is generally a minimum of 36 inches deep if the deck is attached to a structure.
    • Deck footings must be installed below the frost line to prevent shifting due to freeze-thaw cycles. In Pennsylvania, this is generally a minimum of 36 inches deep if the deck is attached to a structure. For freestanding decks, depths less than 36 inches may be permitted and verified on a case-by-case basis if rock or other conditions warrant.
    • Footings must be appropriately sized to support the deck's load, typically rated for 40 pounds per square foot.
    • They should be concrete footings and should not put lateral pressure on the house's foundation.
  • Posts:
    • Single-level wood-framed decks should have posts sized per IRC Table R507.4.
    • While 6x6-inch posts are commonly recommended, 4x4-inch posts may be permitted, depending on specific codes and spans. Always verify with the Township.
    • Posts must be restrained to prevent lateral displacement at the bottom support. This can be achieved with 12 inches of soil or an approved post base connector to prevent displacement at post-to-footing connections.
    • Manufactured post-to-beam connectors should be sized for the specific post and beam dimensions and must be approved galvanized or stainless steel.
    • All bolted connections should use 1/2 inch galvanized bolts with washers under the head and nut.
  • Beams:
    • Beams must follow IRC Tables R507. 5(1-4) based on live load and ground snow load.
    • Beam plies (multiple boards making up a beam) must be fastened together with two rows of minimum 10d nails at 16 inches on center along the edges.
    • Beam ends need at least 1.5 inches of bearing on wood and metal foundations, and 3 inches of bearing on concrete or stone foundations for the beam's full width.
  • Joists:
    • Joist spacing is typically 12 to 16 inches on center.
    • Joists must be attached to beams and joist hangers.
    • Joist ends require at least 1.5 inches of bearing on wood and metal foundations, and 3 inches on concrete or stone foundations for their full width.
  • Guardrails (Railings):
    • If your deck is over 30 inches above the adjacent grade, a guardrail is required for safety.
    • The guardrail must be at least 36 inches high, measured from the deck surface.
    • Baluster spacing must ensure that no opening will allow a 4-inch sphere to pass through.
    • There must also be a 4-inch gap between the deck surface and the bottom rail of the guardrail.
  • Stairs (if applicable):
    • Stair width must be at least 36 inches.
    • Riser height cannot exceed 7.75 inches (if stairs are taller than 30 inches above grade).
    • Tread depth must be at least 10 inches. If the height is less than 11 inches, a 0.75-to 1.25-inch nosing is required.
    • Variations between risers and treads cannot exceed 3/8 inch.
    • Handrails are required for any exterior flight of stairs with more than four risers. Handrails must be between 30 and 42 inches in height, measured vertically above the nosing of the tread.
  • Setbacks: Unenclosed and uncovered porches or decks are generally considered part of the principal building and are subject to setback requirements. While minor projections like eaves are sometimes exempt, decks typically need to adhere to the required yard setbacks for your zoning district. It's crucial to consult the Manheim Township Zoning Ordinance or contact the Planning and Zoning Department for the exact setback requirements for your specific property.

Inspection Requirements

Permits aren't just about paperwork; they also involve inspections to ensure your deck is being built correctly and safely. In Manheim Township, you can generally expect the following inspection stages:

  1. Footing Inspection: This inspection is crucial and must be conducted before pouring concrete for your footings. The inspector will verify the depth, size, and placement of your footings to ensure they are below the frost line and adequately support the deck's load.
  2. Framing Inspection: This inspection takes place after the deck framing is complete, but before you install the decking boards or railings. The inspector will check the lumber sizing, beam and joist connections, ledger board attachment, and lateral bracing to ensure everything is structurally sound.
  3. Final Inspection: Once your deck is completely finished – decking, railings, stairs (if applicable) – a final inspection is required. The inspector will verify that all aspects of the deck meet the approved plans and code requirements. Your deck cannot be used or occupied until all final inspection approvals are obtained.

A helpful note: For decks elevated a minimum of 36 inches above grade, the framing and final inspections may be combined. Always check with the Manheim Township Code Compliance Department for specific inspection protocols and requirements.

The Consequences of Building Without a Permit

We understand the temptation to bypass the permit process to save time or money. However, building a deck without the required permits in Manheim Township can lead to significant headaches and costly consequences, including:

Minigraphic 2
  • Fines and Penalties: Manheim Township can issue fines for violations of its ordinances. These can be substantial, and each day of continued violation can constitute a separate offense.
  • Stop Work Orders: The Township can issue a "Stop Work Order," halting your project immediately, which can result in significant delays and additional expenses.
  • Forced Removal or Alteration: If your deck is built without a permit or doesn't meet code, you may be required to modify it to bring it into compliance, or even worse, tear it down entirely. This is a far more expensive and frustrating scenario than getting the permit in the first place.
  • Safety Hazards: Most importantly, a deck built without permits or proper inspections might not be safe. This puts your family and friends at risk.
  • Insurance Issues: Your homeowner's insurance policy may not cover damages or injuries related to an unpermitted structure.
  • Resale Problems: When you go to sell your home, an unpermitted deck can flag issues during inspection, potentially impacting your home's value and making it difficult to sell.

It's truly not worth the risk!

Why Work with a Local Contractor Who Understands the Code?

This is where a trusted local contractor, like Keystone Custom Decks, becomes your greatest asset. We've been building decks in Manheim Township and the surrounding Lancaster County area for years. This means:

  • Intimate Knowledge of Local Codes: We're not just familiar with the general building codes; we know the specific nuances and requirements of Manheim Township. We keep up-to-date with any changes or amendments.
  • Streamlined Permit Process: We can help you prepare accurate plans and guide you through the application process, minimizing delays and ensuring all necessary documentation is submitted correctly.
  • Code-Compliant Design and Construction: We design and build every deck to exceed code requirements, ensuring your structure is safe, durable, and will pass all necessary inspections.
  • Peace of Mind: When you work with us, you can relax knowing that your deck project is in capable hands and that all legal and safety requirements are being met.

Ready to Build Your Deck the Right Way?

We hope this guide has demystified the deck permit process in Manheim Township for you. Although it may seem overwhelming, following these guidelines is crucial to a successful and enjoyable deck-building experience. Remember, a permit isn't just red tape; it's a safeguard for you, your family, and your investment.

If you're considering a new deck and want to ensure everything is handled correctly, from design to permits to construction, don't hesitate to reach out to us at Keystone Custom Decks. We're here to help you every step of the way, making your dream deck a safe and beautiful reality.

Let's build something amazing together!
